Description
Associated 90053 RC10B6 Builder's Support Kit 2
Champions by Design.1:10 scale 2WD off road has been Team Associated's signature class since the release of the RC10 in 1984. The Team Associated RC10 buggy series has won 13 of the 18 I.F.M.A.R. World Championships contested since the racing class began. In fact, Team Associated has won more 2WD I.F.M.A.R World Championships than all other manufacturers combined!
The RC10B6 Builder's Support Kit 2 brings Team Associated race-winning technology to Builder's assembling dirt oval sprint cars, late models, and custom drag cars. The applications are endless. The Builder's Support Kit has the major sub-assemblies builders need in a value-packed kit, without having to pay for excess 2WD off-road buggy parts.
At the heart of the RC10B6 Builder's Support Kit is the Laydown, Layback, and Standup transmissions with ball differential; all gearboxes are included. Putting the power down is the next-generation Octalock slipper clutch with Factory Team LCF slipper pads. Along with the easy-access rear differential, the rear end includes standard pivot rear blue aluminum arm mounts, 69mm CVA bones and B7 rear hubs. The kit also includes a set of four 13mm Big Bore shocks, all four with 23mm length bodies for custom build applications. Builders need only select an appropriate application, and they can bolt on the suspension, shocks, hubs, drivetrain, and gearbox from the Builder's kit. The opportunities are endless to customize your dirt oval or drag car from any of the B6-based third-party specialty manufacturers in the industry.
Includes:
Ball differential
Laydown, Layback, and standup transmission cases
4x 13mm Big Bore shocks: 23mm shock bodies and 21mm shock shafts with X-rings
2x 13mm shock springs, red fronts
2x 13mm shock springs, orange rear
RC10B6 front end assembly: steering, top plate, suspension, gull wing front arms and blue aluminum front axles
24x Factory Team precision oiled ball bearing set
+1 carbon fiber steering arms
6x 48mm turnbuckles, ball cups, and HD metric ball studs
Rear aluminum arm mounts for use with 69mm CVA bones and RC10B7 rear hubs
Rear aluminum ball stud mount
Aluminum one-piece top shaft
RC10B6.3 servo mounting system with transponder mounting location
Octalock spur gears and 19mm Octalock LCF pads
4x 2.5mm machined shock pistons
Blue aluminum shock bushings
5mm aluminum clamping wheel hexes
Black steel LP serrated wheel nuts
3mm I.D. molded plastic spacers for ball stud and shim needs
Fasteners and metric hardware
Required to Complete:
RC10B6 based dirt oval or drag conversion kit
Conversion-specific body for dirt oval or drag, application
1:10 scale electric motor and electronic speed control
7.4V-7.6V 2S LiPo with "shorty" battery dimensions
Battery charger, 2-channel surface transmitter
2-channel receiver and steering servo
Spray paint for Lexan bodies, Silicone shock fluid
1:10 scale wheels and tires (application specific)
Features:
All 3 B6.1 series gearboxes: laydown, layback, and standup gearboxes included for tuning mass balance to different track surfaces
Hardware included for gearboxes
13mm big bore threaded aluminum shocks (four 23mm bodies and four 21mm shafts) with X-rings for low friction assembly
13mm shock springs (orange front, red rear) for most dirt oval and on-road type applications
Updated B6.4 front end assembly (ball stud mount, steering bellcranks, steering rack, and top plate) with gull wing front arms and blue aluminum front axles
Updated B6.4 -1 scrub caster and steering blocks
Wide pivot rear aluminum arm mounts for use with B6.2 series 69mm CVA bones Fiberglass shock towers
RC10B7 rear hubs, B7 upper caps, and B6.2/B7 +2 CVA axles
B74 rear outer hinge pins included with M3 locknuts
13mm diameter 2.5mm thick machined shock pistons
Updated RC10B7 shock rod ends
5mm aluminum clamping wheel hexes
B6 series Ball differential included
Lightweight aluminum one-piece top shaft
Specifications:
Power Source: Electric
Terrain: Off-Road
Body Style: Buggy
Scale Size: 1:10 Scale
Assembly Level: Kit (This vehicle comes as a kit and must be fully assembled by the user. See "Required to Complete" for extra items needed.)
Width: Varies
Weight: Varies
Internal Gear Ratio: Varies
Drive: 2WD
